EMSBS-SD

Epoch Micro Step Borer S for Aluminium
Enables ultra-deep drilling of minute holes.　New chip-removal stopper technology + high-rigidity neck shape enables high-accuracy drilling of minute holes.

EWSS

Epoch Wonder Drills -Stub
・Tool material : Carbide
・Surface treatment : C
・Tip Angle : 140°
This product is for sale while stock lasts.

EWSR

Epoch Wonder Drills -Regular
・Tool material : Carbide
・Surface treatment : C
・Tip Angle : 140°
This product is for sale while stock lasts.

EMCS

EMC Super Drills -Stub
・Tool material : ESM
・Surface treatment : C
・Tip Angle : 130°

EMCR

EMC Super Drills -Regular
・Tool material : ESM
・Surface treatment : C
・Tip Angle : 120°

GSS

G-Coated Starting Drills
・Tool material : HSS-Co
・Surface treatment : G
・Tip Angle : 90°/135°

SSS

Super SUS Drills -Stub
・Tool material : ESM
・Surface treatment : C
・Tip Angle : 130°

SSR

Super SUS Drills -Stub
・Tool material : ESM
・Surface treatment : C
・Tip Angle : 130°

YKS

Straight Shank Palabolic Flute Drills
・Tool material : HSS-Co
・Tip Angle : 118°

YKL

Straight Shank Palabolic Flute Drills
Long Length Shank Palabolic Flute Drills
・Tool material : HSS-Co
・Tip Angle : 118°

KLE

Straight Shank Palabolic Flute Drills
Extra Long Length
・Tool material : HSS-Co
・Tip Angle : 118°

YSN

Noss Drills(S-Type)
・Tool material : HSS
・Tip Angle : 118°
・Shank：6.5

YMN

Noss Drills(M-Type)
・Tool material : HSS
・Tip Angle : 118°
・Shank：10

YLN

Noss Drills(L-Type)
・Tool material : HSS
・Tip Angle : 118°
・Shank：13

SRM

3S Straight Shank Drills(R-type)
Tool material : HSS

SSM

3S Straight Shank Drills(S-type)
Tool material : HSS

SHM

3S Straight Shank Drills(H-type)
Tool material : HSS

EMSBS-SD

Epoch Micro Step Borer S for Aluminium
Enables ultra-deep drilling of minute holes.　New chip-removal stopper technology + high-rigidity neck shape enables high-accuracy drilling of minute holes.

15NSB-C

Coated Non Step Borer
Non-step height efficiency processing is possible to 15 times of the tool diameter.

20NSB

Non Step Borer
Non-step height efficiency processing is possible to 20 times of the tool diameter.

03WHNSB-TH

★ Carbide Oil Hole Non Step Borer 3D
TH coating improves stability during high-temperature boring.
Specially shaped grooves discharge chips effectively.

05WHNSB-TH

★ Carbide Oil Hole Non Step Borer 5D
TH coating improves stability during high-temperature boring.
Specially shaped grooves discharge chips effectively.

08WHNSB-TH

★ Carbide Oil Hole Non Step Borer 8D
TH coating improves stability during high-temperature boring.
Specially shaped grooves discharge chips effectively.

10WHNSB-TH

★ Carbide Oil Hole Non Step Borer 10D
TH coating improves stability during high-temperature boring.
Specially shaped grooves discharge chips effectively.

15WHNSB-TH

★ Carbide Oil Hole Non Step Borer 15D
TH coating improves stability during high-temperature boring.
Specially shaped grooves discharge chips effectively.

20WHNSB-TH

★ Carbide Oil Hole Non Step Borer 20D
TH coating improves stability during high-temperature boring.
Specially shaped grooves discharge chips effectively.

30WHNSB-TH

★ Carbide Oil Hole Non Step Borer 30D
TH coating improves stability during high-temperature boring.
Specially shaped grooves discharge chips effectively.

02WNSB-TH

★ Carbide Non Step Borer 2D
TH coating improves stability during high-temperature boring.
Specially shaped grooves discharge chips effectively.

03FWHNSB-TH

★ Carbide Oil Hole Non Step Borer for Cast lron 3D
Remarkably high performance for boring in cast iron.
Ideal for environmentally friendly MQL (mist) machining.

05FWHNSB-TH

★ Carbide Oil Hole Non Step Borer for Cast lron 5D
Remarkably high performance for boring in cast iron.
Ideal for environmentally friendly MQL (mist) machining.

10FWHNSB-TH

★ Carbide Oil Hole Non Step Borer for Cast lron 10D
Remarkably high performance for boring in cast iron.
Ideal for environmentally friendly MQL (mist) machining.

15FWHNSB-TH

★ Carbide Oil Hole Non Step Borer for Cast lron 15D
Remarkably high performance for boring in cast iron.
Ideal for environmentally friendly MQL (mist) machining.

20FWHNSB-TH

★ Carbide Oil Hole Non Step Borer for Cast lron 20D
Remarkably high performance for boring in cast iron.
Ideal for environmentally friendly MQL (mist) machining.

30FWHNSB-TH

★ Carbide Oil Hole Non Step Borer for Cast lron 30D
Remarkably high performance for boring in cast iron.
Ideal for environmentally friendly MQL (mist) machining.

03WHNSB-SD

★ Carbide Oil Hole Non Step Borer for Aluminium 3D
TH coating improves stability during high-temperature boring.
Hydrogen-free DLC coating with hardness infinitely close to that of diamond.

05WHNSB-SD

★ Carbide Oil Hole Non Step Borer for Aluminium 5D
TH coating improves stability during high-temperature boring.
Hydrogen-free DLC coating with hardness infinitely close to that of diamond.

15WHNSB-SD

★ Carbide Oil Hole Non Step Borer for Aluminium 15D
TH coating improves stability during high-temperature boring.
Hydrogen-free DLC coating with hardness infinitely close to that of diamond.

20WHNSB-SD

★ Carbide Oil Hole Non Step Borer for Aluminium 20D
TH coating improves stability during high-temperature boring.
Hydrogen-free DLC coating with hardness infinitely close to that of diamond.

25WHNSB-SD

★ Carbide Oil Hole Non Step Borer for Aluminium 25D
TH coating improves stability during high-temperature boring.
Hydrogen-free DLC coating with hardness infinitely close to that of diamond.

30WHNSB-SD

★ Carbide Oil Hole Non Step Borer for Aluminium 30D
TH coating improves stability during high-temperature boring.
Hydrogen-free DLC coating with hardness infinitely close to that of diamond.

ZPBLS-TH

Z Plunging Borer -Long Shank
・Tip angle of 180° (flat) enables plunge boring of not only flat surfaces

ZPB-TH

★ Z Plunging Borer
・Tip angle of 180° (flat) enables plunge boring of not only flat surfaces but also of non-flat surfaces (sloped surfaces, etc.)
