EIKOSHA
TR-P
Tap Remover Plus
Straight Flute (For M14 and over;Helix Angle-Right30°)
Surface treatment：P-Coating
Tool Material：Micro Grain Carbide
Tolerance：d:h7
Work condition
●When processing, use milling machine (General use/NC/MC) Do not use drilling machine, radial drilling machine.
●Use chuck with rigidity.
●Centering should be done with accuracy.
●When processing, use oil cutting fluid.
| Tap Remover Plus：TR-P | ||||||
| Model No. |
Size |
Dia. |
length of |
Effective Length |
Overall |
Shank |
| (D) | (ℓ) | (ℓ2) | (L) | (d) | ||
| TR-P 3 | M3 | 2.2 | 3.5 | 9 | 40 | 6 |
| TR-P 4 |
M4 | 3.1 | 4 | 12 | 40 | 6 |
| TR-P 5 |
M5 | 3.8 | 4 | 15 | 45 | 6 |
| TR-P 6 |
M6 | 4.6 | 4.5 | 18 | 50 | 6 |
| TR-P 8 |
M8 | 6.2 | 5.5 | 24 | 55 | 8 |
| TR-P 10 |
M10 | 7.1 | 6 | 30 | 60 | 10 |
| TR-P 12 | M12 | 8.6 | 6.5 | 30 | 60 | 12 |
| TR-P 14 | M14 | 10.6 | 40 | - | 90 | 16 |
| TR-P 16 | M16 | 12 | 45 | - | 95 | 16 |
| TR-P 18 | M18 | 14 | 50 | - | 100 | 16 |
| TR-P 20 | M20 | 15 | 50 | - | 100 | 16 |
| TR-P 22 | M22 | 17 | 55 | - | 110 | 20 |
| TR-P 24 | M24 | 19 | 60 | - | 120 | 20 |
| Tap Remover Plus：TRL-P | ||||||
| Model No. |
Tap Size |
Dia. |
Length of |
Effective Length |
Overall |
Shank |
| (D) | (ℓ) | (ℓ2) | (L) | (d) | ||
| TRL-P 3 | M3 | 2.2 | 3.5 | 10 | 40 | 6 |
| TRL-P 4 |
M4 | 3.1 | 4 | 20 | 45 | 6 |
| TRL-P 5 |
M5 | 3.8 | 4 | 25 | 50 | 6 |
| TRL-P 6 |
M6 | 4.6 | 4.5 | 30 | 60 | 6 |
| TRL-P 8 |
M8 | 6.2 | 5.5 | 35 | 65 | 8 |
| TRL-P 10 |
M10 | 7.1 | 6 | 40 | 75 | 10 |
| TRL-P 12 | M12 | 8.6 | 6.5 | 40 | 80 | 12 |
