OSG：DG Coated End Mill Series | TOKYO YAMAKATSU CORPORATION

Endmills

OSG

Smooth diamond coating achieved through advanced technology.

Low resistance to minimize the chipping of the workpiece

Without having an edge between the corner radius and the radial relief, it prevents steps on work surface and makes better finish.

・Tool Material：Carbide
・Surface Treatment：DG Coating
・Helix Angle：30°
